Ultrasonic Bath

Price 5000 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Piece

Ultrasonic Bath Specification

Control Type
Digital/Knob Control

Speed Range
Fixed Frequency

Display Type
LED Display

Shape
Rectangular

Heating Capacity
Up to 300W (Optional Heater)

Accuracy
2C (for temperature control)

Power Supply
Mains Powered

Temperature Resistance
Up to 80C

Features
Timer, Heater, Drain Valve, Digital Controls

Type
Ultrasonic Bath

Dimension (L*W*H)
300 x 240 x 150 mm

Equipment Type
Laboratory Cleaning Equipment

Equipment Materials
Stainless Steel Tank, Powder Coated MS Outer Body

Power
150W

Voltage
220V AC, 50Hz

Material
Stainless Steel

Application
Laboratory Cleaning, Medical Equipment Cleaning, Industrial Component Cleaning

Capacity (Ltr)
6 Ltr

Safety Features
Overheat Protection, Fuse Protection

Basket
Mesh Stainless Steel (included)

Timer Range
1-99 minutes

Ultrasonic Frequency
33 kHz / 40 kHz

Body Finish
Anti-Corrosion Powder Coated

Drainage
Yes, provided with Drain Valve

Noise Level
< 60 dB

Tank Capacity
6000 ml

Lid
Supplied with Stainless Steel Lid

Ultrasonic Bath Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
12 Pieces Per Week

Delivery Time
2 Week

About Ultrasonic Bath

Ultrasonic Bath is bonded with ultrasonic transducers that effective convert high frequency electrical energy into ultrasound waves. Further, the created waves create countless microscopic vacuum bubbles which rapidly expand and collapse. We assure our clients that the offered equipment facilitates intense scrubbing of cavitations that cleans away all the dirt and soil from the object immersed. Further, our offered Ultrasonic Bath is fabricated using high grade raw material and sophisticated technology by experienced professionals.

Specification

Country of Origin	Made in India
Frequency	50Hz
Input Voltage Range	170-270 V
Motor Type	AC Motor
Timer Range	0-30/99 Min.

Efficient Ultrasonic Cleaning

Harness advanced ultrasonic frequencies of 33 kHz and 40 kHz to achieve deep, thorough cleansing. This process effectively removes contaminants, residues, and microbial deposits from intricate surfaces that traditional cleaning methods cannot reach, guaranteeing precision without abrasion.

Sturdy Construction and Safety

The bath features a stainless steel tank enclosed by an anti-corrosion powder-coated body, ensuring lasting durability. Safety is paramount, with overheat protection, fuse protection, and a secure lid, allowing continued reliable use in demanding environments.

Flexible Control and User-Friendly Operation

Choose between digital and knob controls, complemented by a clear LED display for easy monitoring. Set cleaning cycles with a timer ranging from 1 to 99 minutes, and manage liquid disposal effortlessly via the built-in drain valve, which improves workflow efficiency.

FAQs of Ultrasonic Bath:

Q: How is the cleaning process carried out in the Ultrasonic Bath?

A: The cleaning process utilizes ultrasonic waves at either 33 kHz or 40 kHz frequencies to agitate the cleaning solution, producing microscopic bubbles. These bubbles implode on the surfaces of items placed in the stainless steel mesh basket, effectively dislodging dirt, residues, and contaminants even from intricate parts.

Q: What types of items can be cleaned using this equipment?

A: This ultrasonic bath is suitable for laboratory glassware, medical equipment, and industrial components, making it versatile for applications where thorough and non-abrasive cleaning is essential. It safely cleans delicate instruments as well as robust metal parts.

Q: When should the timer or heating function be used?

A: You can set the timer anywhere between 1 and 99 minutes based on the level of contamination and cleaning requirements. The optional heating feature (up to 80C and 300W) is useful for enhancing the cleaning effectiveness for stubborn residues or oily substances.

Q: Where should the ultrasonic bath be positioned for optimal use?

A: Place the ultrasonic bath on a stable, flat surface near a mains power outlet. Ensure good ventilation and access to drainage for the integrated valve, especially in laboratory, medical, or industrial cleaning areas for safe and efficient operation.

Q: What are the key usage benefits of the stainless steel mesh basket and drain valve?

A: The mesh stainless steel basket ensures that items are fully exposed to ultrasonic waves and prevents direct contact with the tank surfaces, reducing abrasion risks. The drain valve allows effortless and hygienic removal of used cleaning solutions after the process.

Q: How does overheat and fuse protection improve safety?

A: Overheat protection monitors temperature to avoid excessive heat, while fuse protection prevents electrical faults. Both features safeguard users and equipment, reducing the risk of damage and enhancing reliability during continuous operation.
