Pouch Compression Tester

Name: Pouch Compression Tester
Brand: SUNSHINE SCIENTIFIC EQUIPMENTS
Price: 250 INR
Availability: InStock

Price 250 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Pouch Compression Tester Specification

Voltage
200 Volt (v)

Max Height
450 mm sample height

Operate Method
Automatic

Application
Compression testing of filled pouches and packs

Interface Type
RS232/USB (optional)

Resolution
0.1 kgf

Humidity
Less than 85% RH (Non-condensing)

Response Time
<1 sec

Frequency
50 Hz

Gas Pressure
Not Applicable (Electrical driven)

Power Supply
Electric

Specimen Size
Up to 300 mm width pouch

Accuracy
1% of reading

Measuring Range
0-1000 kgf

Operating Voltage
220V

Features
Data storage, Peak hold function, Overload protection

Number of Specimens
1 at a time

Usage
This apparatus is used for penetration test on a wide variety of materials such as greases

Display Type
Digital LED/LCD

Automation Grade
Semi-Automatic

Equipment Type
Compression Tester

Mounting Type
Floor mounted

Port Size
1/4 inch

Test Range
0-1000 kgf

Product Type
Pouch Compression Tester

Temperature
15C to 40C operating

Capacity
1000 kgf (standard)

Machine Weight
Approx. 150 kg

Test Speed
10-300 mm/min (Adjustable)

Test Width
300 mm

Test Stroke
0-300 mm

Control Mode
Digital/Manual

Platen Size
300 x 300 mm (standard)

Calibration
Included with traceable certificate

Finish
Powder coated body

Drive Mechanism
Motorized screw drive

Safety Feature
Emergency Stop Button, Overload alarm

Compliance Standards
ASTM D642, IS 7028 (where applicable)

Ambient Conditions
Dust free environment recommended

Operation Panel
Soft-key touch control

Data Export Capability
USB/Printer port (optional)

Pouch Compression Tester Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
12 Pieces Per Week

Delivery Time
2 Week

About Pouch Compression Tester

Pouch Compression Tester is widely used for checking the compression strength of different pouches of tea leaves, oil, etc. It is designed in tune international industry standards with the utilization of premium quality components and progressive techniques. Well-known for its accurate result and longer service life, the offered tester is highly demanded in the market. Also, our patrons can avail this Pouch Compression Tester at the most reasonable rate from us.

Specification

Country of Origin	Made in India
Display Type	Digital
Phase	Single
Size	all
Maximum Load	500 kgf
Automation Grade	Automatic
Least Cost	200 Gram
Power Consumption	200 V

High Precision Compression Testing

Engineered for rigorous compression testing, this tester accommodates specimens up to 300 mm wide with an impressive range from 0 to 1000 kgf. Its motorized screw drive ensures uniform load application, while digital controls and adjustable test speed allow fine-tuning for various materials. The robust, powder-coated structure and floor-mounting cater to demanding industrial environments.

User-Friendly Operation and Safety

The operation panel features soft-key touch controls with a clear digital display, simplifying user interface and data retrieval. Safety is inherent through an emergency stop button and overload alarms, providing protection for both the user and specimen during testing. Calibration comes standard, enhancing reliability and traceable measurement results.

Advanced Data Handling and Compliance

Equipped with optional USB/RS232/Printer ports, the tester supports easy data export for analysis and record-keeping. It complies with ASTM D642 and IS 7028 standards, making it suitable for both local and international markets. Additional features like peak hold, overload protection, and storage further enhance its capabilities for quality assurance.

FAQ's of Pouch Compression Tester:

Q: How is the Pouch Compression Tester operated for testing pouches?

A: The tester is operated automatically via a soft-key touch panel. Users place a filled pouch onto the 300 x 300 mm platen, input relevant parameters like test speed (10-300 mm/min), and initiate the test. The machine then applies compression according to preset standards and displays results on the digital screen.

Q: What types of specimens can be tested with this compression tester?

A: This apparatus is suitable for filled pouches and related packaging materials up to 300 mm in width. It supports one specimen at a time, with a maximum test range of 0-1000 kgf, enabling use in quality control for greases, industrial goods, and more.

Q: When should the equipment be calibrated?

A: Calibration is crucial for accurate test results and is included with a traceable certificate upon delivery. It is recommended to recalibrate periodically or whenever significant operational changes occur to maintain 1% accuracy of readings.

Q: Where should the Pouch Compression Tester be installed for optimal performance?

A: For accurate and reliable operation, the tester should be installed in a dust-free environment with ambient temperatures between 15C and 40C and humidity below 85% RH (non-condensing). Proper floor mounting ensures stability during testing.

Q: What process does the machine use to protect users and samples during operation?

A: Safety is ensured through an emergency stop button and an overload alarm, which immediately interrupts the test if abnormal conditions are detected, preventing potential damage to both operator and samples.

Q: How does data export and storage function work on this tester?

A: The equipment offers optional data export capabilities via USB, printer, or RS232 interface. These allow users to transfer, store, or print test results efficiently for analysis or documentation. The built-in peak hold and data storage features aid in quality control reporting.

Q: What are the benefits of using this tester in industrial or quality control environments?

A: Using this tester enables precise measurement of pouch resistance to compression, essential in product development and quality assurance. Features like adjustable parameters, digital readout, fast response, and compliance with international standards streamline workflow while ensuring repeatable, traceable results.
