Ring And Ball Test Apparatus

Price 250 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Ring And Ball Test Apparatus Specification

Product Type
Ring And Ball Test Apparatus

Humidity
Ambient

Power
800 Watt (w)

Interface Type
Analog controls

Mounting Type
Bench-top

Response Time
Immediate (depends on thermometer type)

Measuring Range
Up to 200C

Power Supply
220 V

Operating Voltage
230V AC

Specimen Size
Rings: 17 mm internal diameter, Balls: 9.5 mm diameter steel ball

Features
Stirrer, adjustable heating, glass beaker, insulated body

Resolution
0.1C (digital thermometers optional)

Number of Specimens
2 rings and 2 balls

Capacity
1000 Milliliter (ML)

Accuracy
0.5C

Display Type
Analog (with optional digital upgrade)

Port Size
Standard Laboratory Size

Temperature
Ambient to 200C (using adjustable heater)

Automation Grade
Manual

Equipment Type
Ring and Ball Test Apparatus

Application
Determining softening point of bitumen, tar, and related products

Usage
This apparatus is used for penetration test on a wide variety of materials such as greases

Frequency
50 Hz

Test Range
30C to 200C

Max Height
Approx. 350 mm

Machine Weight
7 kg (approx.)

Control Mode
Manual

Heater Type
Immersion heating coil

Material of Construction
Powder coated mild steel body

Accessories Included
Two steel balls, brass rings, thermometer, and beaker

Stirring Mechanism
Mechanical/manual stirrer provided

Dimensions
225 x 150 x 350 mm (approx.)

Safety Features
Thermal fuse for overheat protection

Ring And Ball Test Apparatus Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
12 Pieces Per Week

Delivery Time
2 Week

About Ring And Ball Test Apparatus

Buy Online the Valiant Ring And Ball Test Apparatus, engineered with a powder-coated mild steel body for enduring lab performance. This top-tier instrument excels in penetration and softening point testing of bitumen, tar, greases, and related materials. The heroic design features a dual specimen setup with two steel balls, brass rings, and precision thermometer, accompanied by mechanical/manual stirring. An immersion coil ensures swift heating, while a thermal fuse adds overheat protection. Pick yours today-now on Sale-for assured accuracy, reliability, and lab safety.

Operational Guidance & Applications

To use this Ring and Ball Test Apparatus, introduce your specimens into the brass rings, place the steel balls on top, and set the beaker on the apparatus. The mechanical/manual stirrer aids uniform heating from the immersion coil. Suitable for laboratories engaged in testing lubricants, bitumen, and tar, it delivers versatile results in viscosity and softening point analysis. Additionally, it's ideal for quality assurance in construction, petrochemicals, and research environments.

Market Availability, Export, and Sampling

The Ring And Ball Test Apparatus is available in the main domestic market of India and is dispatched to prominent international markets. A sample is available on request; charges may apply. Please refer to the current list price for purchase details. Swift dispatching ensures timely delivery to your laboratory or institution. As an exporter, manufacturer, and supplier, our apparatus is meticulously crafted for global scientific communities and quality-focused customers alike.

Specification

Minimum Order Quantity	1 Unit
Country of Origin	Made in India
Heating power	800 W
Power supply	AC 220 V
Capacity of beaker	1000 ml
Temperature resolution	0.01 Degree C

FAQ's of Ring And Ball Test Apparatus:

Q: How does the Ring and Ball Test Apparatus operate for softening point determination?

A: This apparatus utilizes dual brass rings and steel balls for simultaneous testing. By gradually heating the sample using the adjustable immersion coil and stirring for uniform heat, the softening point is recorded as the temperature when the loaded balls cause sample dislodgement.

Q: What materials can be tested with this apparatus?

A: It is suitable for testing bitumen, tar, greases, and related products. The equipment determines the softening point and penetration, making it essential for construction, petrochemical, and lubricant analysis.

Q: When should I use the mechanical versus manual stirrer?

A: Use the mechanical stirrer for consistent and even heating during critical tests for higher accuracy; the manual stirrer offers flexibility for smaller samples or when power supply adjustments are needed.

Q: Where is the Ring and Ball Test Apparatus manufactured?

A: This apparatus is proudly made in India and conforms to high standards required for laboratory use, ensuring reliable test results globally.

Q: What safety features are built into the apparatus?

A: A thermal fuse prevents overheating, protecting both samples and equipment. The powder-coated, insulated body also minimizes accidental heat exposure and enhances overall safety.

Q: How accurate are the measurements delivered by this apparatus?

A: The included thermometer reads with 0.5C accuracy and 0.1C resolution, with the option to upgrade to a digital thermometer for even finer temperature readings.
